Shimano DEORE XT CS-M8100-12
12-speed; 10–45T or 10–51T. Shimano specifies MICRO SPLINE. Select the matching Pro 5 Micro Spline assembly rather than an HG or XD body.
Shimano cassette specificationsWHEELSETS · HUBSETS · DRIVETRAIN
One hub. Several connections.
Build around the standard Hope Pro 5 148 mm Boost rear hub. The cassette, rim and brake each impose their own requirements.
01
Choose the exact Pro 5.
The standard 148 mm Boost rear hub is offered with 6-bolt or Centrelock rotor mounting and 24, 28, 32 or 36 spoke holes. Choose those interfaces before ordering.
Hope Pro 5 148 mm specificationsHope documents separate Micro Spline and XD/XDR 108-engagement freehub assemblies. Its e-bike documentation includes different 54-engagement assemblies. Keep the hub version and service parts together.
Identify the version in Hope’s hub documentsThe Pro 5 DH hub is a separate product designed for seven-speed DH cassettes. Do not apply the twelve-speed examples below to that hub.
Hope DH hub limits02
The cassette chooses the freehub interface.
SRAM XG-1295 · CS-XG-1295-A3
This specific Eagle model lists 10–50T gearing, XD driver and Eagle chain technology. Use the appropriate Pro 5 XD configuration. Other XG-1295 revisions can differ.
SRAM model-specific specificationsInterface comparison: the published cassette and freehub standards agree in these pairings. That does not establish the rest of the drivetrain. Confirm the derailleur’s range, chain and shifter generation separately. XD and XDR installation arrangements must follow the relevant instructions.
03
Prefer a wheel already built?
Hope’s Fortus 30 SC Pro 5 is a trail/enduro option that brings the hub, rim and spokes together. Its published recipe includes:
- 32-hole J-bend Pro 5 hub; 6-bolt or Centrelock options.
- 27.5- or 29-inch aluminium rim, 30 mm internal width.
- Sapim Race double-butted stainless spokes and brass nipples.
- Micro Spline, SRAM XD and Shimano freehub options.
- 32 mm tubeless tape, valve and wipe supplied.
Hope describes the rim profile for 2.4–2.8-inch tires. The tire, sealant, cassette and brake rotor still need selection.
Choose the exact rear-spacing variant. Hope’s page lists several widths but also uses a general 142 × 12 mm supplied-conversion statement; confirm the ordered 148 mm wheel configuration with the seller.
Hope Fortus 30 SC options & data sheets04
Custom example: Pro 5 with a DT Swiss EX 511.
Build proposal · requires wheel-builder confirmation
For a 29-inch trail/enduro build, the EX 511 variant RDEX51CDPW32SA6298 provides a concrete rim specification to compare with a 32-hole Pro 5 hub.
| Part | Recorded specification | Still needed |
|---|---|---|
| Hub | Standard Pro 5 148 mm Boost, J-bend, 32 holes | Frame/axle fit, cassette interface and rotor version |
| Rim | EX 511 29-inch, 32 holes, 30 mm internal width, 601 mm ERD | Riding/load suitability and tire selection |
| Nipples & washers | DT lists Pro Lock Squorx aluminium nipples and PHR washers with this rim | Use the rim-specified hardware in the build |
| Spokes | J-bend connection; 32-spoke assembly | Model, lacing pattern, left/right lengths and tension plan |
| Inflation | Rim has a Presta valve hole and hooked tubeless interface | Compatible tire, tape, valve, sealant or tube |
DT Swiss exact rim variants & support
Matching hole counts is only the start. Calculate spoke lengths from the exact hub geometry, rim ERD, nipples and lacing pattern. No spoke length is prescribed here without those inputs.
05
Choose the tire and its supporting parts.
For the 29-inch, 30 mm internal-width examples above, begin with a 29 × 2.4 tubeless tire. The choices below are candidates with published dimensions; frame clearance, casing suitability and the complete rim/tire pairing still need confirmation.
Schwalbe Nobby Nic
11654143.01: 29 × 2.40, ETRTO 62-622, ADDIX SpeedGrip, Super Ground, folding, TLE. This is the exact specification on the linked product page, not every Nobby Nic version.
Exact tire specificationManufacturer pairing: Schwalbe recommends Doc Blue Professional for its TLE tires. Its current quantity guidance for 62–100 mm tires is 90–120 ml per tire.
Doc Blue 3711.01 · quantity & instructionsMaxxis Minion DHR II
Maxxis lists its 2.40 and 2.50 sizes for 30–35 mm internal rims. Select a 29 × 2.40 version marked TR, then choose the casing and compound for your riding. Those choices are not interchangeable product identifiers.
Compare DHR II sizes, casings & compoundsMaxxis requires a tubeless-compatible rim and liquid sealant for TR installation. This is an alternative tire path; the Schwalbe sealant pairing at left is not a Maxxis-specific endorsement.
Maxxis TR requirements06
Tubeless is a five-part system.
| Part | Selected route | Check before use |
|---|---|---|
| Tape | Hope Fortus 30 SC: supplied 32 mm tape. Custom EX 511: DT Swiss lists 32 mm tape for 29–30 mm internal rims. | Use the rim’s installation directions; inspect coverage and adhesion. |
| Valve | Fortus wheel: supplied valve. Custom wheel: tubeless Presta valve with a base that seals the rim bed. | Choose sufficient exposed length for the pump; verify the base and rim fit. |
| Sealant | Nobby Nic TLE path: Doc Blue, 90–120 ml for the listed 62 mm tire. | Shake and follow current instructions; check liquid level during service. |
| Tube option / spare | Choose a tube whose size range includes 62-622, with the correct valve. | Verify tire/rim permission for tube use. Remove the separate tubeless valve before fitting a tube. |
| Repair supplies | Pump, compatible tire levers, valve-core tool, suitable tube or tubeless repair kit. | Select patches for the tube material; sealant does not repair every cut. |
Record both the rim and tire pressure limits and follow the more restrictive applicable limit. A printed maximum is not a recommended riding pressure. Rider load, terrain and casing influence the operating choice.
07
What changes with another rim?
DT Swiss EX 511
The custom example above uses the 29-inch, 32-hole variant with 601 mm ERD and the specified PHR washers and Squorx nipples. It keeps the proposed 32-hole Pro 5 hub, subject to the wheel builder’s lacing and spoke calculations.
Return to the exact EX 511 buildENVE AM30
ENVE lists 30 mm internal width, 28 holes, 3 mm rim offset and a 605 mm ERD for the 29-inch rim. Its suggested tire range is 2.3–2.6 inches.
ENVE AM30 specificationsThis is a separate 28-spoke build proposal. It cannot replace the rim in the 32-spoke example unchanged. Choose a matching hub drilling and recalculate spoke lengths, accounting for the rim offset and required hardware.
ENVE tire and tube requirementsENVE identifies AM30 as hookless and permits inner tubes only with a tubeless or tubeless-ready tire. Carry those requirements into the tire choice; do not transfer the EX 511’s hooked-rim assumptions to it.
08
The other side of the hub: the brake.
Select the rotor attachment with the hub: 6-bolt or Centrelock. Then match the rotor’s diameter and thickness to the caliper, frame and adapter. The hub attachment alone does not settle those dimensions.
For example, Hope’s Vented rotor is 3.3 mm thick and made for V4 brakes; Hope excludes it from EVO GR4 compatibility. A matching six-bolt hub would not remove that restriction.
Concrete six-bolt example
A Hope Floating 6 Bolt rotor, 203 mm × 1.8 mm, matches the attachment of a six-bolt Pro 5. Hope’s EVO GR4 page excludes the Vented rotor; use the ordinary floating rotor route as the example to assess with that brake.
Floating rotor dimensions & mountingStill conditional: the frame must allow a 203 mm rear rotor, the caliper mount needs the correct adapter, and the floating carrier must clear surrounding parts. No adapter is selected without the frame’s native mount size. A 200 mm rotor is not the same dimension.
09
Bring a complete question to the wheel builder.
- BikeFrame model/year, rear axle and spacing, wheel diameter, tire clearance and intended use.
- DrivetrainExact cassette model/range, freehub version, chain, derailleur and shifter.
- WheelExact hub and rim variants, spoke count/type, nipple system, calculated lengths and build specification.
- BrakeRotor attachment, diameter, thickness, caliper and adapter.
- ServiceKeep the selected hub’s exploded diagram, freehub diagram and bearing/tool references with the build.
The Pro 5 Micro Spline drawing identifies bearings, pawls, springs, seals and drive-side spacers separately. A bare freehub body is not the entire conversion assembly. Confirm all required pieces against the exact hub.
One starting order: 29-inch trail rear wheel
- Factory assemblyFortus 30 SC Pro 5, 29-inch, 148 mm Boost rear, six-bolt, MICRO SPLINE. Confirm the exact ordered variant.
- DriveCS-M8100-12 10–51T cassette with the linked XT shifter, derailleur and chain recipe.
- Tire systemNobby Nic 11654143.01, supplied Hope tape/valve, Doc Blue sealant. Rim/tire fit and frame clearance require confirmation.
- Brake route203 × 1.8 mm Hope Floating six-bolt rotor; suitable brake and frame-specific adapter, with frame diameter approval still required.
- Before purchaseResolve frame clearance, permitted loads/use, axle fit, brake mount and all selected variants. No stock or whole-bike approval is claimed.
Sources checked September 28, 2026. Factory specifications and our custom-build proposal are identified separately. Neither example confirms fit to an unnamed bike.
